Hydrated Lime Production Line

Hydrated Lime Production Line advantages

1. The inside of the digester adopts NM400 replaceable stirring gear design to reduce equipment wear.

2. The stirring gear of the digester adopts the plow-type stirring gear, which reduces the power of the equipment and reduces the impact of the starting current of the equipment.

3. Digest and install an adaptive fan adjustment system for dust removal. When the air volume needs to be processed changes (steam volume increase or decrease, observation port opening and closing, dust collection hood opening and closing, pipeline loss design increase, etc.), the fan is automatically adjusted to reduce power consumption.

4. The lightweight powder separator adopts the design of circulating air negative pressure, which can avoid accidental dust leakage while ensuring the energy saving of circulating air.

5. The interior of the lightweight separator is lined with NM400 wear-resistant steel plate, and the air inlet of the finished product collector adopts ceramic welting technology to prevent internal wear of the equipment.

6. Increase the thermal conversion catalytic system. Use the equipment’s own heat energy to heat the water for digestion, plus the digestion reaction to recover part of the water vapor and reduce water vapor emissions.

7. The F series integral reducer is adopted, and the main shaft is a through-shaft design. Avoid unbalanced equipment operation caused by coaxiality errors.

8. The blades of the digester are arranged out of order and staggered. Avoid problems such as torque fluctuations caused by uneven materials.

9. The digestion dust collector adopts the integrated design of digestion and dust removal. Makes the structure more compact, and the dust removal powder (superfine powder) is directly discharged into the three-stage digestion and then enters the powder selection equipment.

10. Screw conveyor adopts variable pitch conveying. Reduce the conveying capacity and reduce the wear of spiral blades.

11. The internal blades of the screw conveyor are extruded and formed by NM400 wear-resistant steel plate to ensure the service life.
